VFD Automatic Square bottom paper bag making machine

Square paper bag making machine is suited for various bags, such as Takeaway Food Packaging Bag, Greaseproof Brown Kraft Paper Bags, Popcorn bags, Fast food bags.

Weight 5000 kg
Dimensions 10000 × 1600 × 1750 cm
Max paper roll diameter

1300mm

Material core diameter

76mm

Max production speed

200pcs/min

Power weight

19-23kw

Clear

Detail about VFD Automatic Square bottom paper bag making machine

VFD Series Adjustable Rolling Square Bottom Paper Bag Machine, it has the advantages of high speed, high production efficiency, and large adjustment range. This equipment is to glue the original color or printed roll paper by the machine at one time, and fold it into micro, cut the paper tube, coat the bottom, shape the bottom of the bag, and discharge the bag. The whole machine is controlled by the computer central control system. The touch screen displays, the servo motor controls the length of the paper bag and can produce paper bags of various specifications. It is the first choice for the production and processing of the whole bag.

MODEL CY-180 CY-290 CY-330 CY-460
Bag length

Bag width

191-371mm

80-190mm

260-533mm

120-290mm

260-533mm

140-330mm

260-533mm

220-460mm

Bottom size 50-100mm 60-180mm 60-180mm 60-180mm
Paper thickness 50-120gsm 60-150gsm 60-150gsm 60-150gsm
Maximum roll width 320-600mm 320-900mm 320-900mm 600-1300mm
Max paper roll diameter 1300mm 1300mm 1300mm 1300mm
Material core diameter

Max production speed

76mm

200pcs/min

76mm

200pcs/min

76mm

200pcs/min

76mm

180pcs/min

Power

weight

 19kw

5000kg

23kw

8500kg

23kw

9000kg

23kw

10000kg

Machine size(mm) 10000*1600*1750 11000*2500*1800 11000*2600*1800 11000*3000*1800

Characteristics

1.Use hydraulic lifting for material handling, and automatic: tension control system for unwinding,

2. Side gluing uses Italy ZATOR.

3. Automatic error correction uses Italy SELECTRA.

4. Paper tube forming device with a thumb-cut function.

5. Automatic stop for having no material.

6. Center clip, drum wheel clamp, and drum wheel mechanical finger are all use spider synchronous adjustment mechanical design, which can significantly reduce the adjustment time for· replacing size.

7. Use German KEB servo with the SICK photoelectric eye, which can accurately track the printed material.

8. Equipped with automatic lubrication supply system and jams alarm system.
